ESTONE 120x120 Electrical Deck Oven
| Product code : | ESTONE 120x120 |
| Category : | Ovens |
| Labels : | oven , commercial oven , restaurant oven |
| Stock : | - |
The major specification of electrical deck oven is that each deck can be operated independently. The heating system
is designed with special stonebased and ceramic resistances that provide the heating disturbing on the baking surface
and it balances the heat while baking. Thus, it provides an opportunity to bake different sort of products in each deck.
In order for the products to be fermented, there is a yeasting chamber available and its temperature and humidity can
be adjusted as per request. It is used with single deck also modular and according to need it can be added extra deck,
chimney hood and yeasting chamber. It provides low energy consumption. Thanks to its wheels it can be moved easily
| MODEL | ESTONE 120x120x1 |
ESTONE 120x120x2 |
ESTONE 120x120x3 |
ESTONE 120x120x4 |
|---|---|---|---|---|
| Capacity (Loaves of Bread / 8 hours) | 430 | 860 | 1290 | 1720 |
| Baking Surface (m²) | 1.44 | 2.88 | 4.2 | 5.76 |
| Number of Decks / Palette Numbers | 1/2 | 2/2 | 3/2 | 4/2 |
| Inner Width of Oven (mm) | 1200 | |||
| Inner Depth of Oven (mm) | 1200 | |||
| Inner Height of Oven/Height of Deck Entry (mm) | 215 / 190 | |||
| Width - A (mm) | 1650 | |||
| Depth/Length - B (mm) | 1615 | |||
| Height - C (mm) (Wheeled) | 1730 | 1860 | 2090 | 2420 |
| Max. Depth/Length - D (mm) | 2100 | |||
| Max. Height - E (mm) (Wheeled) | 1810 | 1940 | 2170 | 2500 |
| Min. Ceiling Height - F (mm) (Wheeled) | 1980 | 2110 | 2340 | 2670 |
| Weight (kg) | 830 | 1080 | 1300 | 1510 |
| Power Consumption (kw) - Electrical | 13.8 | 21.4 | 28.2 | 35.6 |
| Power Consumption (kw) - Gas (optional) | 10.2 | 15.6 | 21.8 | 28.2 |
